Engine start circuit
а - with an automatic transmission; б - with a mechanical gear box; 1 - the block of the relay and safety locks in a motor compartment; 2 - the ignition switch; 3 - fuse of the engine start circuit and ignition coils; 4 - rechargeable battery; 5 - see pos. 9; 6 - the relay of a starter; 7 - connection with the "mass" of the engine; 8 - connection with the "body" of the body; 9 - see pos. 5; 10 - with burglar alarm; 11 - without burglar alarm; 12 - see pos. 23; 13 - the relay block in salon; 14 - alarm burglar alarm; 15 - not used; 16-ECU alarm system; 17 - starter; 18 - the engine; 19 - a flywheel; 20 - pinion; 21 - overrunning clutch; 22 - the lever privada; 23 - relay armature; 24 - the electric motor; 25 - traction relay; 26 - the switch of the lever of a choice of transfers of an automatic transmission
